LV20017 up to LV20022

  • Updated

ledvion balk.png

LV20017_Content-01.svg

  • LED Tube (1PCS)
  • Instruction Manual
  • LED Starter

INSTALLATION INSTRUCTION



INTRODUCTION & WARRANTY
Thank you for selecting and buying Ledvion product. Ledvion will serve you the best. Please read instructions carefully before starting the installing and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product. They are retained and ready to serve you at the best. The warranty is valid for 3 years from the date of purchase. The warranty does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no warranty against damage to any surface due to incorrect removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This product is warranted for manufacturing defects only. The LED tube can be used in hotels, offices, factories, conference rooms, meeting rooms, commercial complexes, residential buildings, schools, colleges, universities, hospitals, etc.



WARNING!

  • Installation should only be done by a certified electrician
  • Operation environment temperature: from -20ºC to +40ºC
  • Do not use DC electricity
  • Do not modify the fitting to be used with the LED tube
  • Ledvion LED Tubes are NOT designed to be used in emergency operations
  • This lamp may not be suitable for use in all applications where a traditional fluorescent lamp has been used. The temperature range of this lamp is more restricted. In cases of doubt regarding the suitability of the application the manufacturer of this lamp should be consulted
  • This lamp is designed for general lighting service (excluding for example explosive atmospheres)



New Fitting Installation

  • Installation should only be done by a certified electrician
  • Switch Off the power
  • Ensure the wiring diagram is followed as highlighted
  • Insert Ledvion LED tube
  • Switch On the power to test the light

Installation & Replacement of Fluorescent Lamp

  • Installation should only be done by a certified electrician
  • Please refer to the wiring diagram for replacing fluorescent tube on a Retrofit EM ballast circuit with Ledvion LED tube
